Model coverage
This Toyota Prius model page covers 23 indexed years from 2004-2026 with exact-year service pages for module, security, and calibration data.
Choose a year
Prius Module Programming & Calibration
The Toyota Prius features TSS (2016+). The 5th generation (2023+) introduced a completely new ADAS sensor layout requiring updated calibration procedures.
3,200+
Vehicles supported
1-Year
Unlimited warranty
Same-Day
Mobile in DFW
OEM-Grade
Native diagnostics
MODEL SERVICE SNAPSHOT
What Core Auto Logic can do for the Toyota Prius
ADAS evolution
Across indexed Toyota Prius years, documented sensor systems include TSS 3.0 Forward Camera (XW60 Prius - 5th Gen), TSS 3.0 Forward Radar (77 GHz - XW60), Blind Spot Monitor Sensor - Left (BSM), Blind Spot Monitor Sensor - Right (BSM), and Rear Cross Traffic Alert (RCTA); 157 calibration trigger records are indexed across the model line.
View generationsProgrammable modules
The indexed Toyota Prius years include 670 programmable module records across exact-year pages.
View yearsGateway and security
This model line includes 72 gateway, immobilizer, or key-security records across indexed years.
View yearsCore Auto Logic capability
Core Auto Logic supports model-line diagnostics, exact-year module programming, security-access planning, and ADAS calibration where equipped for the Toyota Prius.
Read model FAQAvailable years
Years we service for Prius
23 model years with documented module and calibration coverage.
Prius 2026
Module and calibration coverage
Prius 2025
Module and calibration coverage
Prius 2024
Module and calibration coverage
Prius 2023
Module and calibration coverage
Prius 2022
Module and calibration coverage
Prius 2021
Module and calibration coverage
Prius 2020
Module and calibration coverage
Prius 2019
Module and calibration coverage
Prius 2018
Module and calibration coverage
Prius 2017
Module and calibration coverage
Prius 2016
Module and calibration coverage
Prius 2015
Module and calibration coverage
Prius 2014
Module and calibration coverage
Prius 2013
Module and calibration coverage
Prius 2012
Module and calibration coverage
Prius 2011
Module and calibration coverage
Prius 2010
Module and calibration coverage
Prius 2009
Module and calibration coverage
Prius 2008
Module and calibration coverage
Prius 2007
Module and calibration coverage
Prius 2006
Module and calibration coverage
Prius 2005
Module and calibration coverage
Prius 2004
Module and calibration coverage
ADAS EVOLUTION
How Toyota Prius ADAS has changed
7 platform generations from 2004 to 2026.
1
XW20 (2nd Gen, 2004-2009)
2004 - 2009 HS-CAN (500 kbps) - ISO 15765-4 compliant; OBD2 DLC Pin 6/14
ADAS SYSTEMS (1)
Rear View Camera
Complete mobile calibration and module programming available. Specific protocols vary by trim and replaced hardware. [EPA] 1.5L | I4 | Regular | Front-Wheel Drive | Automatic (variable gear ratios) | ...
2
XW30 (3rd Gen, 2010-2015)
2010 - 2014 HS-CAN (500 kbps) - ISO 15765-4 compliant; OBD2 DLC Pin 6/14
ADAS SYSTEMS (1)
Rear View Camera
Complete mobile calibration and module programming available. Specific protocols vary by trim and replaced hardware. [EPA] 1.8L | I4 | Regular | Front-Wheel Drive | Automatic (variable gear ratios) | ...
3
ZVW30/XW30 Prius platform - verify exact generation by VIN in Toyota TIS
2015 - 2018 Multi-CAN bus (PT-CAN powertrain/HV, Body-CAN, HV-CAN); HV Gateway ECU bridges 1...
ADAS SYSTEMS (6)
Forward Camera (verify by VIN) Forward Radar (verify by VIN) Blind Spot Monitor Sensor - Left (BSM) Blind Spot Monitor Sensor - Right (BSM) Rear Cross Traffic Alert (RCTA) Rear View Camera
Complete mobile calibration and module programming available. Specific protocols vary by trim and replaced hardware. [EPA] 1.8L | I4 | Regular | Front-Wheel Drive | Automatic (variable gear ratios) | ...
4
ZVW52 (Toyota Prius Prime Gen 1 PHEV, 2017-2022)
2017 - 2022 CAN bus (ISO 15765-4); Toyota Multi-CAN (PowerTrain CAN + Body CAN + HV CAN); OB...
ADAS SYSTEMS (11)
Pre-Collision System (PCS) - Forward Camera (TSS-P) Radar Cruise Control / Pre-Collision Millimeter-Wave Radar (TSS-P) Lane Departure Alert (LDA) - TSS-P Automatic High Beams (AHB) Forward Camera (Monocular) TSS-P Millimeter-Wave Radar (RCC/PCS) Lane Departure Alert (LDA) / AHB - TSS-P Forward Radar (77GHz) Lane Keep Assist / Lane Departure Warning (LKA/LDW) Pre-Collision System PCS+ (TSS-P Final Year) - Camera TSS-P Millimeter-Wave Radar (PCS+)
Toyota Prius Prime 2017 - ZVW52 PHEV platform. 1.8L Atkinson-cycle + electric motor, 8.8 kWh Li-ion HV battery, 25-mile EV range (SAE), WLTC rating 68.2 km. Level 2 AC charging (240V/3.3 kW onboard ch...
5
XW50 TNGA-C (4th Gen)
2019 - 2022 Multi-CAN bus (PT-CAN powertrain, Body-CAN, HV-CAN); HV Gateway ECU bridges 12V ...
ADAS SYSTEMS (11)
Forward Camera (TSS-P - XW50 Prius Specific) Forward Radar (77GHz) Automatic High Beam (AHB) HUD (Head-Up Display - Limited trim only) Forward Camera (TSS-P - XW50 Specific) Prime: EV Charge Port / Charging System Camera (if equipped) Forward Camera (TSS-P - FINAL YEAR this PN) Forward Camera (TSS 2.0 - NEW PN for 2022) Forward Radar (77GHz - TSS 2.0) Proactive Driving Assist Emergency Steering Assist (ESA)
XW50 4th Gen Prius, TNGA-C platform. Powertrain: 1.8L 2ZR-FXE Atkinson-cycle + MG1/MG2 motor-generators, 1.3 kWh NiMH HV battery, 121 hp system output. E-CVT (no conventional transmission). Trims: L, ...
6
XW60 TNGA-C (5th Gen - Complete Redesign)
2023 - 2026 Multi-CAN bus (PT-CAN, Body-CAN, HV-CAN); HV Gateway ECU bridges 12V and lithium...
ADAS SYSTEMS (14)
Forward Camera (TSS 3.0 - XW60 Specific) Forward Radar (77GHz - TSS 3.0) Proactive Driving Assist with Steering Emergency Steering Assist (ESA) Automatic High Beam (AHB) HUD (Head-Up Display - XLE Premium standard) Rear Cross Traffic Braking / RCTA (if equipped) TSS 3.0 Forward Camera (XW60 Prius - 5th Gen) TSS 3.0 Forward Radar (77 GHz - XW60) Blind Spot Monitor Sensor - Left (BSM) Blind Spot Monitor Sensor - Right (BSM) Rear Cross Traffic Alert (RCTA) Automatic High Beams (AHB) Rear View Camera
XW60 5th Gen Prius, redesigned TNGA-C platform - COMPLETE REDESIGN from XW50. Do NOT apply any XW50 (2019-2022) procedures, part numbers, or calibration specs to this vehicle. Powertrain: 2.0L M20A-FX...
7
XW60 (Toyota Prius Prime Gen 2 PHEV, TNGA-C, 2023-2024)
2023 - 2026 CAN bus (ISO 15765-4); Toyota Multi-CAN (PowerTrain + Body + HV CAN + LIN); OBD2...
ADAS SYSTEMS (5)
TSS 3.0 Forward Camera (PCS+, LDA+, AHB) Forward Radar (77GHz) Lane Trace Assist (LTA) / Lane Departure Alert+ (LDA+) Rear View Camera TSS 3.0 Forward Camera (PCS+, LDA+, LTA, AHB)
Toyota Prius Prime 2023 - complete platform redesign to TNGA-C (XW60). New 2.0L Dynamic Force Atkinson + electric motor, 13.6 kWh Li-ion HV battery (vs 8.8 kWh ZVW52), 44-mile EV range (EPA), 220hp co...
FREQUENTLY ASKED QUESTIONS
FAQ
Which ADAS systems does the Toyota Prius have, and which require calibration after collision repair?
Prius ADAS: Rear view cam, Forward Camera (TSS 2.0 or TSS 3.0 by year), 77GHz forward radar, BSM L/R, RCTA, ESA, AHB, HUD. Camera, radar and BSM sensors need post‑repair calibration. Verify year; Techstream required.
Can you reset the airbag/SRS light on a Toyota Prius?
Yes - we clear SRS faults and reset the light after repairs if crash DTCs are resolved and modules are intact. Module replacement or coding uses our diagnostic software and Techstream on TNGA‑C Prius.
What's involved in programming a replacement ECU/PCM for the Toyota Prius?
Replacement ECU/PCM requires VIN programming, immobilizer registration and CAN network coding. We use OE‑grade tools and Techstream. Hybrid/PHEV Prius (AWD‑e available) may need additional HV system steps.
Do you support all-keys-lost (AKL) on the Toyota Prius?
Yes - AKL handled via authorized locksmith workflow and immobilizer reprogramming. Proof of ownership required. Smart key provisioning uses our diagnostic software and Techstream, especially on hybrid/PHEV AWD‑e variants.
What's needed after windshield replacement on a Toyota Prius?
Windshield change often requires forward camera recalibration (TSS 2.0/3.0), AHB and HUD alignment if equipped. Verify model year and use Techstream; mobile or shop calibration available for TNGA‑C Prius.
Can you service a Toyota Prius on-site, mail-in, or both?
Both. We perform on‑site calibrations and windshield/ADAS work with OE‑grade tools, and accept mail‑in modules for programming, SRS reset and key work. Techstream required for ADAS/HV work on Prius.
Generations
Prius generation guides
Start at the generation guide that matches your build, then drill into the exact model-year page for module, security, and calibration specifics.
MODEL SERVICE SNAPSHOT
What Core Auto Logic can do for the Toyota Prius
Model coverage
This Toyota Prius model page covers 23 indexed years from 2004-2026 with exact-year service pages for module, security, and calibration data.
Choose a yearADAS evolution
Across indexed Toyota Prius years, documented sensor systems include TSS 3.0 Forward Camera (XW60 Prius - 5th Gen), TSS 3.0 Forward Radar (77 GHz - XW60), Blind Spot Monitor Sensor - Left (BSM), Blind Spot Monitor Sensor - Right (BSM), and Rear Cross Traffic Alert (RCTA); 157 calibration trigger records are indexed across the model line.
View generationsProgrammable modules
The indexed Toyota Prius years include 670 programmable module records across exact-year pages.
View yearsGateway and security
This model line includes 72 gateway, immobilizer, or key-security records across indexed years.
View yearsCore Auto Logic capability
Core Auto Logic supports model-line diagnostics, exact-year module programming, security-access planning, and ADAS calibration where equipped for the Toyota Prius.
Read model FAQService pathways
Plan Toyota Prius service by exact year
Start with the model-year page before quoting module, security, or calibration work. Each year page carries the indexed systems and notes for that build.
Priority model-year pages
Common service pages
ADAS calibration for Toyota Prius Camera, radar, blind-spot, and post-repair calibration support. ECU programming and cloning for Toyota Prius VIN write, donor ECU setup, bench cloning, and immobilizer pairing. SRS and airbag module reset for Toyota Prius Crash-data clear, replacement RCM setup, and post-repair scan support. Immobilizer and key programming for Toyota Prius Add-a-key, all-keys-lost, and post-module-swap security pairing.
Prius by the numbers
Coverage depth for this model line
Model-level coverage rolls up the year records indexed for Toyota Prius.
23
Years catalogued
2004-2026
Year span
25
ADAS systems indexed
8
Generations
0
Part numbers indexed
Generation timeline
Prius chassis evolution
Grouped by chassis platform when indexed on the model-year records.
2023-2026 Platform XW60
Indexed generation
5th Gen XW60
2016-2022 Platform XW50
Indexed generation
4th Gen XW50
2010-2015 Platform XW30
Indexed generation
3rd Gen XW30
2004-2009 Platform XW20
Indexed generation
2nd Gen XW20
Toyota reference
See the broader Toyota coverage map
Use the make page for brand-wide ADAS evolution, tools, and model navigation.
